BMW 1M / 1 Series / Z4 Ohlins Upgrade

Ohlins have developed a range of compatible coilover kits to suit individual BMW chassis which are fully serviceable by BG Motorsport right here in the UK. The Ohlins designed shock absorbers offer damping and rebound adjusters to ensure comfort on bumpy back roads as well as optimum performance when finding the limits on a track. So whatever your driving style you can have your car responding accordingly.

1M – Part No. BMZMN01, E82, 2011-2012
1 Series – Part No. BMSGP01, F20, F21 2011-
Z4 – Part No. BMSMP50, Z89, 2009-2012

General Features

• DFV (Dual Flow Valve) • Rebuildable • Corrosion salt spray tested (ISO 9227) • 2 year Limited Warranty • Height adjustable • High speed valve, E82 • Adjustable compression and rebound, E82

FRONT

• McPherson Strut • Single bleed adjuster • Spring preload adjuster (approx. 15 mm lower than standard) • Coil Springs (60 N/mm) • Dustcovers • Use with original top mounts

REAR

• Conventional Shock Absorber • Single bleed adjuster • Separate spring preload adjuster (approx. 10 mm lower than standard) E82 • Separate spring preload adjuster (approx. 20 mm lower than standard) E89 • Coil Springs (120 E82, 110 E89) N/mm • Dustcovers • Use with original top mounts
